Instruction Manual V 1.3 – 12/2003

Fig. 14

→

• Remove the splash protector.

• Fill the wax bath (Fig. 15) with wax pellets up

to the top.

• Press BACK and REAGENT STATUS to ac-

cess the reagent status table (Fig. 14). High-

light the wax bath you just filled and press

SET AS FULL.

• After about 90 minutes, add another 0.5 kg

of wax pellets.

• The pellets will take a total of approx. 10

hours to melt.

Important!

During the melting process, the paraf-

fin level MAY NOT drop below the

MIN level (2, Fig. 15).

• Once the paraffin is completely molten, re-

insert the splash protector.

Software control

• The software calculates when the wax will

be ready for use and selects program start-

ing times accordingly, i.e. the paraffin will

definitely be molten when it is required for

the first paraffin step.

Filling with wax pellets

5. Operation

Fig. 15
