Instruction Manual V 1.3 – 12/2003

4.4 Setting up the data connections

Printer (optional)

• Lift off the instrument console flap (12).

• Connect the printer to the printer port (7) via

a standard Centronics cable (refer Fig. 6).

Other connections

• For additional data transfer and storage the

instrument console is equipped with a stan-

dard 1.44 MB floppy drive (10) for 3.5“ dis-

kettes and with an RS 232 serial port (11) .

Only instruments which satisfy the re-

quirements for SELV circuits may be

connected to interfaces (7), (8), (9)

and (11).

Fig. 6

4. Setting up the instrument
